Fullrange 40mm 4ohm 3w Multimedia Speaker

This 40×18mm round full-range speaker with a neodymium magnet delivers robust performance, featuring a rated power of 4W (6W max) and 4Ω impedance. Its high-energy neodymium magnet system ensures outstanding sensitivity and dynamic response across the entire frequency range. The specially designed spirally-curved paper cone, combined with an extra-compliant rubber surround, achieves an optimal balance for enhanced low-frequency performance and overall sound quality, with a bass extension down to 250Hz.

Key Features & Benefits:

Round Design with Mounting Step: The circular shape maximizes the vibrating area within a compact space, improving acoustic efficiency. The integrated mounting step facilitates easy and secure sealing fixation during installation.

Neodymium Magnet: Provides a strong magnetic field in a small, lightweight package, resulting in fast response, high efficiency, and powerful output.

Paper Cone & Rubber Surround: The paper cone delivers natural sound reproduction, while the compliant rubber surround allows for long-excursion movement, which is key to producing more powerful bass.

Metal Frame (Chassis): Features a sturdy iron frame with a black anodized finish, ensuring product stability, reliable operation, and long-term durability.

Bass Response down to 210Hz: Delivers solid bass performance for its compact size. The effective frequency range extends up to 20kHz, with an average sensitivity of 85dB SPL at 0.5m with 1W input.

.

The 40mm 4ohm 3w speaker is one type of electronic components, Our XDEC is a professional speaker manufacturer for 16 years, we have rich experience,

included mylar speaker, multimedia speaker,speaker box, headphone speaker and so on,

welcome contact us for more info ~

widely used in intercom,two way radio,smart home devices, smart speakers, smart TVs, game consoles, laptops, and desktop computers. They deliver exceptional sound quality, boasting clear highs, rich mid-tones, and deep bass, catering to the diverse audio expectations of manufacturers. Specifically, they are well-suited for high-fidelity audio devices, security monitoring systems, and multimedia audio devices.

This dimension diagram provides a comprehensive  overview of the physical attributes and specifications of the 40mm 4ohm 3w neodymium speaker, aiding in its proper installation and integration into Audio Device designs.

The frequency response curve helps us understand the speaker's performance across different frequencies, in cluding treble,midrange, and bass. Fluctuations on the curve indicate sound quality in specific ranges. A flatter curve suggests a more balanced output, while larger fluctuations indicate volume changes at certain frequencies.
